Xiamen Woodsply is the professional manufacturer and exporter of wood products including H20 Beam, 3-Ply Shuttering Panel, Film Faced Plywood, OSBect, for formwork & scaffolding usage. Our office locates in Xiamen which is the international harbor in China.

We mainly export plywood, Laminated Veneer Lumber, 3 ply plywood, film faced plywood, HDF, MDF (medium density fibreboard), Three Ply Shuttering Panels, Softwood Scaffold Panel(Pine LVL scaffolding Plank), Shuttering Plywood, formwork H20 Timber Beam (Wood Girder), particle board, melamine board, Pine Plywood, HMR MDF,blockboard, OSB board,etc. Our products meet E1/E2 Standard.

The quality of our products is under strict control. All the machines are working automatically. All of our products have passed the test and all the physical data meets the strict DIN1045 standard. We shall send you test reports as soon as we get your inquiry. (Most of the test results are much higher than the standard.)
Contact information
Contact Person: Steve Woods
Tel: +86-592-5141177
Mobile: +86-137-9928-0177
Fax: +86-592-5063767
Email: woodsply@gmail.com
H20 Beam Composing

Our products H20 Beam are composed by following parts:

A) Material: Spruce / Pine.
B) Flange: Solid Wood 40x80mm
C) Web: 3 or 5 PliesStructure, 30mm thickness. or Plywood, 13-15 Plies, 22mm thickness.
D) End: PUV / Plastic protection, Or cut to hexagon



H20 Beam Specifications
Weight per running meter: 4.8-4.9kg
Bending moment -- max. 5kN.m
Shear force – min 11.0kN
Bending – max 1/500
Live load (Bending stiffness)
Max 500kN/m2
H.S. Code 2007: 44186000.90
Available Length: (in CM)

180 – 245 – 290 – 330 – 360 – 390 – 420 – 450 – 490 – 590

H20 Beam Product characteristics
The price is cheap, the even formwork price is about 80% of the steel formwork.
Just the degree is big, the weight is light.
General use is widely, can be used for the even formwork, the curve formwork, building formwork etc..
The system product parts standardizes degree is high, reused well, meet the environmental protection request.

Loading quantity: depands on the length of the beams
Pictures of Products
